Ford Focus RS Mk2, ST225 & Volvo S60R / V70R — 2.5 5-Cyl Turbo Performance Ignition Coils
The Volvo Modular 5-cylinder turbo is the sleeper engine of the 2000s — powering the Focus ST225 Mk2, Focus RS Mk2 (305 bhp), the legendary RS500 (350 bhp), and Volvo's S60R / V70R 300 bhp AWD flagships. All of them share the same coil-on-plug assembly, and every one of them lives on boost. MTP-1009 is a direct plug & play replacement engineered in the UK, delivering 12% more spark energy across all 5 cylinders — same fitment, better heat handling, cleaner ignition when the turbo's spooled hard.
- Years
- 2003 – 2014
- Chassis
- DA3 · P1 · P2 · P3 · CD345 · C70 II
- Engine code
- B5254T3 · B5254T7 · B5244T · B5234T · Duratec HYDA / HYDB
- Engine
- 2.5 5-cylinder turbo (Modular platform)
- Power
- 220 – 350 bhp
- Coils needed
- 5 × Mantis MTP-1009 - Ford / Volvo 1.6 EcoBoost GTDi Performance Ignition Coil
Set includes all 5 coils. Only need one? Choose "Just 1 coil" if you're replacing a single failed unit.
Signs your 2.5 Duratec H Turbo / Volvo B5254T Modular 5-Cyl needs new coils
- Misfire codes P0301–P0305 on Ford IDS, ELMconfig, VIDA/DiCE or a generic OBDII scanner
- Rough idle when cold — especially after sitting overnight
- Noticeable loss of top-end pull above 4,000 rpm on boost
- Fuel economy dropping without another obvious explanation
- Intermittent check-engine light that clears on next start
- Boost feeling "flat" on hard throttle in mid-range — classic Mk2 RS / R symptom
Installation notes
Direct plug & play — no coding, no dealer tools required, identical fitment across Ford Duratec H and Volvo B52xx variants. Remove the engine cover (Focus RS/ST: 3x 10mm nuts; Volvo R: pull-off clips), pull the OE coils, unclip the connectors, and swap in the MTP-1009s. Because these are 5-cylinder turbo engines living on boost, always replace as a set of 5 — mixed-age coils cause uneven spark distribution and the ECU pulls timing to compensate, which kills the performance benefit of the new units. Torque coil bolts to 8 Nm. Total install time: 25–35 minutes on Focus, slightly longer on Volvo R due to intake plumbing.
Common questions
Will this fit my Focus RS Mk2 / ST225 / Volvo R without coding?
Yes. Direct plug & play replacement — the ECU reads MTP-1009 identically to the OE Ford / Volvo coil. No coding, no Ford IDS or Volvo VIDA work needed on any 2.5 5-cyl variant, including RS500.
Do I really need all 5, or can I just replace one?
We strongly recommend replacing all 5 as a set. If one coil has failed, the other four have seen identical heat and hours — they're likely close behind. Mixed-age coils cause uneven spark, and the ECU compensates by pulling timing, which loses the performance benefit of the new coils. That said, if you're in a bind and just need to get the RS moving, one MTP-1009 will absolutely work as a temporary fix.
I'm running a Mountune or Revo tune / MP350 map — is this coil up to it?
Yes — this is where the 12% spark-energy upgrade earns its keep. Tuned Mk2 RS / RS500 and mapped Volvo R cars push cylinder pressures well beyond factory spec, and OE coils are a known weak link on hard-mapped 5-cylinders. MTP-1009 has more headroom for boost, better heat dissipation in the neodymium primary core, and UK-engineered QA — same physical fit, same connector, same wiring, straight swap.
This coil also fits
Full application list — Ford Duratec H 2.5T & Volvo B52xx Modular 5-cylinder:
- Ford Focus ST Mk2 (DA3, 2005–2010) — 225 bhp
- Ford Focus RS Mk2 (DA3, 2009–2011) — 305 bhp
- Ford Focus RS500 Mk2 (2011) — 350 bhp, 500-unit limited run
- Ford Kuga Mk1 2.5T (2008–2012)
- Volvo S60R / V70R (P2, 2003–2007) — 300 bhp AWD
- Volvo C30 T5 (P1, 2007–2013) — 227 bhp
- Volvo S40 / V50 T5 (P1, 2004–2012) — 220–230 bhp
- Volvo C70 II T5 (2006–2013)
- Volvo S60 II T5 (2011) — 300 bhp Polestar variants included
- Volvo V70 III T5 (2008–2014)
- Volvo S80 II T5 (2007–2010)
- Volvo XC70 II T5
- Volvo XC90 2.5T (2003–2014)
OE cross-references
These are the original manufacturer part numbers this coil directly replaces. Check the number stamped on your existing coil against this list before ordering to confirm your fitment.
Ready to fit your Ford / Volvo 2.5 Duratec H Turbo / Volvo B5254T Modular 5-Cyl?
Full set · £149.95 · UK dispatch · Direct plug & play
