Ford Fiesta ST Mk8, Puma ST & Focus 1.5 EcoBoost — Performance Ignition Coils
The Fiesta ST Mk8 is what most people quietly agree is the last true hot hatch — a 200hp 1.5 EcoBoost triple with a proper mechanical LSD, in a car small enough to actually enjoy on a British B-road. Same 1.5 EcoBoost lives in the Puma ST, Focus Mk4 1.5 EB, and Kuga Mk3 — three cylinders, one turbo, one coil-on-plug per hole. MTP-1013 is a direct plug & play replacement engineered in the UK, delivering 12% more spark energy on every one of those three cylinders — the exact platform Mountune, Revo and Cobb tunes lean on hardest when they push the 1.5 EB past 250hp.
- Years
- 2018 – 2024
- Chassis
- B479 · CX703 · J2K · CX482
- Engine code
- M1JE · M1JJ · M1JA · M1JC
- Engine
- 1.5 EcoBoost 3-cyl turbo
- Power
- 150 – 200 bhp
- Coils needed
- 3 × Mantis MTP-1013 - Ford Fiesta ST Mk8 / Focus ST / Puma ST 1.5 EcoBoost Ignition Coil
Set includes all 3 coils. Only need one? Choose "Just 1 coil" if you're replacing a single failed unit.
Signs your Fiesta ST Mk8 · Puma ST · Focus Mk4 1.5 EcoBoost · Kuga Mk3 needs new coils
- Misfire codes P0301, P0302 or P0303 on FORScan or a generic OBDII scanner
- Rough idle when cold — 3-cylinder engines feel every dropped spark
- Judder or stumble at 2,500–3,500 rpm under boost
- Loss of top-end pull above 5,000 rpm, especially on a Mountune / Revo tune
- Fuel economy falling off without another explanation
- Intermittent engine management light that clears on the next start
Installation notes
Direct plug & play — no coding, no FORScan work, no IDS required. Pop the engine cover (two 8mm bolts), disconnect each coil connector, single 8mm bolt per coil, lift out, drop the MTP-1013 in, torque to 8 Nm and reconnect. On a 3-cylinder engine always replace as a set of 3 — the ECU compares cylinder-to-cylinder combustion via the crank sensor, and a mixed-age set of coils causes it to pull global timing to protect the weakest hole, which erases the performance benefit of the new units. Total install time: 15–20 minutes on Fiesta ST / Puma ST, slightly longer on Focus and Kuga due to the deeper engine bay.
Common questions
Will this fit my Fiesta ST Mk8 / Puma ST / Focus 1.5 EB without coding?
Yes. Direct plug & play — the Ford PCM reads MTP-1013 identically to the OE Motorcraft DG-555 coil. No FORScan, no IDS, no coding of any kind needed on Mk8 Fiesta ST, Puma ST, Focus Mk4 1.5 EB or Kuga Mk3.
Do I really need a full set of 3, or can I just replace one?
We strongly recommend replacing all 3 as a set. On a 3-cylinder engine one weak coil is enormously obvious — the missing power stroke is a full third of the engine — and if one coil has failed the other two have seen identical heat, hours and boost. Mixed-age coils cause uneven spark energy across the three cylinders, and the ECU compensates by pulling timing globally, which loses the performance benefit of the new coil. If you're roadside-stuck a single MTP-1013 will absolutely get you home, but plan to do the set.
I'm running a Mountune / Revo / Cobb tune — is MTP-1013 the right coil?
Yes — this is exactly the platform we built it for. Tuned 1.5 EBs run higher cylinder pressures than stock and the OE Motorcraft coil starts blowing out spark above ~230hp on ethanol maps. MTP-1013 uses a UK-engineered neodymium core delivering 12% more spark energy, which is what keeps the burn clean at Mountune m235 / Revo Stage 2 / Cobb Stage 2 boost levels. Same physical fit, same connector, same wiring — no map changes needed.
This coil also fits
Full application list — Ford 1.5 EcoBoost 3-cylinder (HX7G / GN10170 family):
- Ford Fiesta ST Mk8 (2018+) — 200 bhp 1.5 EcoBoost
- Ford Fiesta Mk8 1.5 EcoBoost 150 (2017+)
- Ford Puma ST (2020+) — 200 bhp 1.5 EcoBoost
- Ford Puma 1.5 EcoBoost mHEV (2019+) — 155 bhp
- Ford Focus Mk4 1.5 EcoBoost Titanium / ST-Line / Vignale (2018+) — 150–182 bhp
- Ford Kuga Mk3 1.5 EcoBoost (2019+) — 150 bhp
- Ford EcoSport 1.5 EcoBoost (facelift, 2018+)
OE cross-references
These are the original manufacturer part numbers this coil directly replaces. Check the number stamped on your existing coil against this list before ordering to confirm your fitment.
Ready to fit your Ford Fiesta ST Mk8 · Puma ST · Focus Mk4 1.5 EcoBoost · Kuga Mk3?
Full set · £89.97 · UK dispatch · Direct plug & play
