BMW E46 318i/320i, E87 1-Series, Mini Cooper S R56 & Peugeot 208 GTi — Performance Ignition Coils
The BMW N42 / N43 / N46 / N13 four-cylinder — and its co-developed PSA Prince cousin (Peugeot 1.6 THP / VTi, Mini Cooper S R56, Citroën DS3 Racing) — is one of the most widely-shared engine families in Europe. Two decades of E46 318i and 320i, E87 and E90 1/3-series, Mini Cooper S R56 and JCW, Peugeot 208 GTi and 308 GTi, Citroën DS3 Racing, Volvo C30 — all running the same coil-on-plug design. And all of them share the same weak spot: the OE coils cook under sustained heat and start misfiring long before the plugs are due. MTP-1007 is a direct plug & play replacement, UK-engineered, delivering 12% more spark energy through a redesigned primary winding and neodymium core.
- Years
- 2001 – 2018
- Chassis
- E46 · E81 · E82 · E87 · E88 · E90 · E91 · E92 · E93 · E85 · E86 · F20 · F21 · R56 · R57 · R58 · R59 · R60 · R61
- Engine code
- N42 · N43 · N46 · N13 · N14 · N18 · EP6 · EP6DT · EP6CDT · EP6DTS
- Engine
- 1.6 – 2.0 four-cylinder petrol
- Power
- 115 – 208 bhp
- Coils needed
- 4 × Mantis MTP-1007 - BMW E46 / Peugeot Citroen 1.6 VTi Performance Ignition Coil
Set includes all 4 coils. Only need one? Choose "Just 1 coil" if you're replacing a single failed unit.
Signs your BMW N42/N43/N46/N13 & PSA Prince 1.6 VTi / THP needs new coils
- Misfire codes P0301–P0304 on INPA, ISTA, Carly or generic OBDII
- Rough cold-start idle — the classic Prince-engine tell
- Stumble on part-throttle acceleration around 2,000-3,500 rpm
- CEL that clears then returns, especially in cold weather
- Loss of pull on the Cooper S / 208 GTi under boost
Installation notes
Direct plug & play — no coding, no INPA / ISTA work required. On the BMW N42/N46 family, pop the plastic engine cover, unclip the coil connectors, single 10mm bolt each coil, coils lift straight out. On the Mini Cooper S R56 and Peugeot / Citroën 1.6 THP, access is tighter — the coil pack sits under the plastic engine cover on the rear of the head. Always replace as a set of 4 — mixed-age coils cause uneven spark and the DME/ECU pulls timing to compensate, killing the performance benefit. Torque to 8 Nm. Total install: 20 minutes on the E46 / E90, 30 minutes on the R56.
Common questions
Will this fit my E46 318i / E90 320i / R56 Cooper S / 208 GTi without coding?
Yes. Direct plug & play replacement — the DME (BMW) or ECU (PSA) reads MTP-1007 identically to the OE coil. No coding, no INPA, no ISTA, no Diagbox work required across any of the platforms.
Do I really need all 4, or can I just replace the misfiring one?
We strongly recommend replacing all 4 as a set. If one coil has failed, the others have seen identical heat and hours — they're likely close behind. Mixed-age coils cause uneven spark, and the ECU compensates by pulling timing, which loses the performance benefit of the new coils. Especially true on the Mini Cooper S R56 and Peugeot 208 GTi where cylinder pressures are highest.
I've got a Mini Cooper S R56 / JCW — do these fit the Prince 1.6 THP (N14 / N18)?
Yes. The BMW-PSA joint-venture Prince engine (N14 / N18 on BMW nomenclature, EP6DT / EP6CDT / EP6DTS on PSA) uses the same coil design across the R56 Cooper S, R58 Coupé, R59 Roadster, R60 Countryman JCW, and the entire Peugeot 208 GTi / 308 GTi 270 / DS3 Racing range. One coil, all platforms.
This coil also fits
Full application list — BMW N-series & PSA Prince family:
- BMW E46 318i / 320i (N42 / N46, 2001-2006)
- BMW E87 / E81 / E82 / E88 1-Series 116i / 118i / 120i (N42 / N43 / N46, 2004-2013)
- BMW E90 / E91 / E92 / E93 3-Series 316i / 318i / 320i (N43 / N46, 2007-2013)
- BMW E85 / E86 Z4 2.0i (N46, 2005-2009)
- BMW F20 / F21 1-Series 114i / 116i (N13, 2011-2018)
- Mini R56 / R57 / R58 / R59 Cooper S / JCW (N14 / N18, 2007-2016)
- Mini R60 / R61 Countryman / Paceman Cooper S / JCW (N18, 2010-2016)
- Peugeot 207 GT / GTi / RC (1.6 THP, 2007-2012)
- Peugeot 208 GTi & GTi 30th Anniversary (1.6 THP, 2013-2018)
- Peugeot 308 / 308 GT / 308 GTi 270 (1.6 THP, 2007-2018)
- Peugeot 3008 / 5008 (1.6 THP, 2010-2016)
- Citroën C3 Picasso, C4, DS3 (incl. DS3 Racing) (1.6 VTi / THP, 2007-2018)
- Citroën DS4 / DS5 (1.6 THP, 2010-2018)
- Volvo C30 / S40 / V50 1.6i (2007-2012)
OE cross-references
These are the original manufacturer part numbers this coil directly replaces. Check the number stamped on your existing coil against this list before ordering to confirm your fitment.
Ready to fit your BMW / Mini / Peugeot / Citroën / DS / Volvo BMW N42/N43/N46/N13 & PSA Prince 1.6 VTi / THP?
Full set · £119.96 · UK dispatch · Direct plug & play
